Mastering the Ultra HID System Installation: A Step-by-Step Guide

Are you unsure how to install the Ultra HID System from GTR Lighting that you recently purchased? There's no need to search any further! This thorough guide will help you ensure a flawless installation by following each step. Please take note of the following caution before we begin for your own safety and best outcomes.

Warning

You agree that this tutorial is intended only as an instructional tool by following it. No particular result is guaranteed, and GTR Lighting and its distributors are not responsible for any harm, abuse, or damage. If in doubt, get professional help and proceed with caution.

Installation Steps

Clean the HID Bulb Glass

The glass capsule should be cleaned with an alcohol pad and allowed to air dry before turning on any HID lamps. Then, carry out the installation.

Connect Bulbs to Ballasts

The latches on the AMP connectors should be fully engaged.

Pass-through Wiring with Housing Caps

Due to internal wiring, headlights require removing a cap (often made of plastic) to reach the bulb. Drill a hole in your factory housing cap to make sure the grommet fits snuggly.

Bi-Xenon Wiring

The GTR Lighting harness manages the high/low switching and supplies power to the HID components in Bi-Xenon HID systems. Connect the HID system components using the given schematic.

Troubleshooting

Are you having trouble installing it? The following are some possible issues and fixes:

  • Make sure bare metal is used for grounding.
  • Connect the ring terminal to an adequate power supply.
  • Look for a bad fuse fitment or a blown harness fuse.
  • Make sure that the car is supplying power to the headlight circuit.
  • Verify the input plug's pinout. If the high beam function is not present, switch the blue and white wires in the input connector. The blue and brown wires should be changed for reversed functions.

Prioritize safety! Exercise caution at all times when handling electrical components. If you properly follow this guide, you may install your HID system successfully. If you are unsure, always consider hiring a professional installer.

Product Highlights

  • Benchmarking: The Ultra Series 35w HID Ballast from GTR Lighting is painstakingly made to surpass rivals. With its quick ignition and efficient power delivery, this ballast guarantees excellent performance under all circumstances.
  • Simple Installation: Measuring only 2.75 by 3.5 inches, this small ballast can be easily installed anywhere and comes with a grounding strap and all necessary mounting gear.
  • Cutting Edge Technology: Bulb-out alerts and flickering lights are over. Even the most complex circuits are managed by an ASIC controller and integrated Can bus technology.
  • Durability: Made from high-quality materials, this ballast is expected to last. The Ultra Series Ballast is made to last, regardless of possible wear and tear or road shocks.
  • HR Tested: We at Ledlightjeep thoroughly test our goods to guarantee that you get nothing but the best.

Specifications

  • 35w of power
  • 9006 was entered. Men
  • 1 AMP male and 1 AMP female output
  • 9–16 V DC input voltage
